Vortex VX9

PN
1143060 Vortex VX9 with 8.5" x 11" DD Vortex Raider™ Searchcoil
Click to explore the Vortex VX9
Garrett Vortex VX9 control panel
+
+
+
+
+
+
+
+
+
+
+
+
+
+

VX9


MORE POWER THAN VX7

This professional Metal Detector model is designed for serious treasure hunting, featuring a full three-tiered accurate target ID display, including two ferrous scales to help filter out unwanted iron trash. It offers different types of detection modes, including FAST Mode for competition hunts and high-trash areas. The THIN COINS Mode enhances detection of fine, low-conductivity targets like hammered silver and gold coins. Additional adjustable sensitivity settings, superior audio control, and multiple frequency choices make this high-quality metal detector ideal for professionals seeking precise detection depth and accuracy.
Full Three-Tiered MD-MF Target ID Scale
When using multi-IQ technology, the VX9’s accurate target ID system features a non-ferrous scale along with two ferrous scales to distinguish valuable finds from unwanted iron trash. This professional metal detector enhances accurate detection, ensuring complex targets register across multiple scales simultaneously. With adjustable sensitivity, detection modes, and superior audio control, the VX9 provides precise detection depth for treasure hunting in various environments.

More target information . . . so you can make better dig decisions!
Thin Coins Mode (VX9 only)
Designed for precision treasure hunting, this specialized detection mode is optimized for locating small, thin coins like hammered silver and tiny ancient gold coins. The gold detector ensures accurate detection with enhanced sensitivity settings, allowing users to pinpoint low-conductivity targets with ease.




Faster recovery speed.

Enhanced Response on select Target ID range.

Target Response reduced for common ferrous items and high-tone targets.

Fast Mode
Engineered for treasure hunting in high-trash environments, this detection mode helps uncover valuable targets hidden among debris. Ideal for competition hunts, it features a fast recovery speed to quickly distinguish between signals and a reduced iron volume setting to minimize interference from unwanted metal.
3 Levels of Recovery Speed Control
Select from three recovery speeds to optimize your metal detecting experience. A higher recovery/reactivity speed allows for better target separation, making it easier to distinguish valuable finds from nearby debris. This feature is especially useful for competition hunts and detecting in areas with heavy metallic trash, where good targets might otherwise be masked. Combined with an advanced search coil, adjustable sensitivity level, and precision detection modes, it ensures superior accuracy and performance in challenging environments.
Vortex searching beach
Includes Beach Mode and Multi-Frequency Salt Operation!
Harness the power of MD-MF Technology and Multi-Salt operation for smooth performance and accurate target ID in challenging environments. This waterproof metal detector delivers exceptional detection depth along wet beaches and in the surf, ensuring precise identification of targets even in mineralized conditions. Equipped with a waterproof search coil and full waterproof capability, it is fully submersible up to 16 feet, making it ideal for underwater treasure hunting and metal detecting in any terrain.
Wireless Ready!
With built-in Z-Lynk wireless technology, you can enjoy a completely cord-free metal detecting experience. It allows for easy connection to wireless headphones, offering low latency and superior sound quality while you search.

Garrett MS-3 or CS-3 Z-Lynk wireless headphones and other Z-Lynk accessories sold separately
Seven (7) Frequency Options
Select from five powerful single frequencies (5 kHz, 9 kHz, 13 kHz, 18 kHz, or 25 kHz) or use one of two Vortex simultaneous Multi-Frequency options—Metal mode for general outdoor treasure hunting, or Multi-Frequency Salt for effective saltwater beach use. These versatile settings provide tailored detection for a variety of environments, ensuring optimal performance and accurate target ID across different soil conditions and treasure types.
Search Mode Versatility


Choose from 7 options:

  • Thin Coins Mode

  • Fast Mode

  • Zero Discrimination

  • Beach Mode

  • Standard Mode (ideal for hunting relics, jewelry, and most international coins)

  • USA Coins Mode

  • Custom Mode
Iron Volume
Control What You Hear
The Iron Volume feature lets you decrease the volume of ferrous (iron) targets, while maintaining the normal volume for non-ferrous targets. This is particularly useful for experienced treasure hunters who prefer hearing all signals but want the option to minimize unwanted iron noise. With eight adjustable levels, you can fine-tune the settings for a more focused search, enhancing your metal detecting experience by reducing distractions without missing valuable finds.
Lightweight and Collapsible!
This collapsible metal detector features a foldable design, compacting to just 24.75" (62.86 cm) for easy storage and extending to 56.75" (144.14 cm) for comfortable use.

Weighing only 3 lbs. (1.38 kg) with the coil cover installed, it's the perfect choice for those who want a portable yet powerful tool for treasure hunting.

MD-MF Technology Explained
Introducing the world’s first fully upgradeable waterproof detector series! With the VX-5, you can enhance your capabilities as your skills grow by upgrading to the VX-7 or VX-9 models through software updates. Each Vortex model upgrade unlocks additional operating frequencies, advanced features, and increased power.


SUBMERSIBLE TO 16 FEET (5 METERS)
Suba diver underwater scanning with a Garrett Vortex metal detector.




Search streams, lakes, and the ocean coast with your Vortex.



Garrett Vortex Submersible Headphones with a 1/8" (3mm) jack are sold separately.
EASY-ACCESS POWERFUL MENU OPTIONS
Hi-Resolution Ground Balance
With 175 points of ground balance resolution, this detector offers precise adjustments for environments ranging from ferrous ground to saltwater, ensuring accurate detection in various conditions.

Volume Control
For both the built-in speaker and headphones

Eight Sensitivity/Depth Adjustments

Iron Audio
Garrett’s unique feature accurately identifies complex iron objects, such as bottle caps and steel washers, helping to distinguish valuable targets from unwanted debris.

Seven Search Modes + Pinpoint

Frequency Shift
Use to reduce noise or electrical interference (EMI)

Backlight
Illuminate your LCD screen with the backlit display to easily view target information, even in low-light conditions.

World’s first fully transformable detector series!


As your skills increase, transform your VX7 into a VX9.
Vortex Series Comparison Chart
Vortex VX5 Vortex VX7 Vortex VX9
MD-MF
Target ID Scale
One Target ID Scale
(0-99)
2-tier Target ID Scales 3-tier Target ID Scales
Frequencies 13 khz, Multi-Freq. 5, 13 kHz, Multi-Freq.,
Multi Salt
5, 9, 13, 18, 25 kHz,
Multi-Freq., Multi-Salt
Search Modes Zero, Standard, USA
Coins, Custom
Zero, Standard, USA
Coins, Beach, Custom
Zero, Standard,
USA Coins, Thin Coins,
Beach, Custom, Fast
Bottlecap Reject (MF function) Fixed Yes Yes
Iron Boundary (MF function) Fixed Fixed Yes
Notch Discrimination Yes Yes Yes
High-Resolution Iron Discrimination Yes Yes Yes
Sensitivity settings 8 8 8
Variable Recovery Speed Fixed Yes: 2 settings Yes: 3 settings
Z-Lynk Wireless Yes Yes Yes
Channel (EMI Reduction) Yes Yes Yes
Increased sensitivity/depth N/A Yes Yes
Auto Ground Balance Yes Yes Yes
Number of Tones 3 3, 5 3, 5
Volume Control Yes Yes Yes
Iron Audio™ Yes Yes Yes
Iron Volume Yes Yes Yes
Button Lock (Dive Mode) Yes Yes Yes
Pinpoint Yes Yes Yes
LCD Backlight Yes Yes Yes
Battery Condition Indicator Yes Yes Yes
Length (Adjustable) 24.75" to 56.75"
(62.86 cm - 144.14 cm)
24.75" to 56.75"
(62.86 cm - 144.14 cm)
24.75" to 56.75"
(62.86 cm - 144.14 cm)
Total Weight (with 8.5" x 11" coil) 3 lbs (1.38 kgs) 3 lbs (1.38 kgs) 3 lbs (1.38 kgs)
Fully Waterproof to 16 ft (5m) 16 ft (5m) 16 ft (5m)
Warranty 3 Years,
Limited Parts/Labor
3 Years,
Limited Parts/Labor
3 Years,
Limited Parts/Labor

Updateable / Upgradeable Yes Yes Yes
Vortex Searchcoils
Vortex searchcoils have a unique waterproof connector and are not compatible with other Garrett detectors.
Garrett 5 inch by 8 inch DD Vortex Ripper Searchcoil
5" x 8" DD Vortex Ripper™ Searchcoil
PN: 2238500

COMING SOON
Garrett 6 inch by 11 inch DD Vortex VIPER Searchcoil
6" x 11" DD Vortex Viper™ Searchcoil
PN: 2238300

GARRETT DIRECT
Garrett 8.5 inch by 11 inch DD Vortex Raider Searchcoil
8.5" x 11" DD Vortex Raider™ Searchcoil
PN: 2238400

Included with Vortex Metal Detector
14 inch by 11 inch DD Vortex Reaper Searchcoil
14" x 11" DD Vortex Reaper™ Searchcoil
PN: 2238600

GARRETT DIRECT
Vortex Headphone Options
Garrett CS-3 Z-Lynk Wireless Headphones
PN: 1635510

GARRETT DIRECT
Garrett MS-3 Z-Lynk Wireless Headphones
Garrett MS-3 Z-Lynk Wireless Headphones
PN: 1627710

GARRETT DIRECT
Garrett Vortex Submersible Headphones
Garrett Vortex Submersible Headphones with 1/8" (3mm) jack
PN: 2202150

GARRETT DIRECT
Garrett ClearSound Easy Stow Headphones with 1/8" (3mm) jack and in-line volume control
Garrett ClearSound Easy Stow Headphones with 1/8" (3mm) jack and in-line volume control
PN: 1612750

GARRETT DIRECT
Vortex Manual & Quick Start Guide
Vortex Manual and Quick Start Guide


Click to view or download a Vortex Manual and Quick Start Guide.


English

Italian

Spanish

French

German

Accessories

Digging tools, treasure pouches, Keepers finds box, and sand scoops.
Garrett Z-Lynk wireless kits, headphones, and accessories.
Gear up for the field with Garrett daypacks and protective detector bags.
Standard use, fully submersible, and wireless headphone options.
Garrett branded shirts, caps, and informative treasure hunting books.
